PCB Factory

Fabrication & Support

Are you looking for pcb factory to help you save cost? Prsgroup is your best choice

From the prototype to the series assembly

We adapt to your individual needs. Flexibility and best pricing are our strengths,

On-time delivery

Quickest turn 12hours for 2-layer pcb/ 24hours for 4-layer pcb

We not only stand for flexibility, but also for quality

Pcb are ISO and UL qualified,we supply only high quality pcb

*Competitive pricing is a key strengh of ours

Referenzen

Partners

How we work

All kinds of different files are acceptable

1. Meeting your needs

The more information you can provide us with during the offer phase, the better and more targeted we can be at meeting your needs.

This includes, for example, the following information:

PCB data (All kinds of different files are acceptable)

Pick'n'Place file including all SMD and THT components to be assembled

Parts list/BOM including manufacturer's name for each item, ideally as an Excel file

Assembly plan as a PDF file

If required, your detailed specification of the circuit board, THT assembly or mechanical structure.

Special pcb and hard-to-find components are not problems

2. PCB and component reference

a: We fabricate the our own pcb with best prices
b：We therefore work with a large number ofsuppliers in order to not only achieve the best posible price for you with the shortest possilble delivery times but above all to be able to offer consistently high quality.
Do you still have your own material in stock? No problem, we wil be happy to equip the components you provide.
c: We also supply assembly services( turkey services )

Flexibility

3. Flexible manufacturing

After all points have been clarified individually, we come to our flagship discipline: equipping. No matter whether Special material pcb , multilayer pcb,SMD, THT or mixed assembly , we are in our element here. Your order will receive our full attention, regardless of whether it is an individual prototype or a series assembly.

The cornerstone of our flexibility is our in-house assembly software, which creates a setup program directly from your saved project data. This means we can not only implement your order quickly, but also safely.

Strict qualtiy control

4. Quality control

Speed and flexibility are worthless if the quality is not right. That's why our experienced employees meticulously check each assembly for errors before we hand over your assembly to its destination and ship it to you.

Production-of Pcb and Pcba

Inquiry form

Personal Information

First and last name*

E-Mail*

Telephone

Business

Address

Web

Lead time

Country

Technical specifications

Lagen

Bezeichnung*

Artikelnr.

Lieferformat

Größe in mm*

Stückzahl*

Oberfläche

Leiterbahnabst., -breite, Restring

Min. Bohrungen

Material

Material (mm)

Endkupfer außen

Lötstopp

Lötstopp (Farbe)

Positionsdruck

Falls das Produkt in Zukunft öfter gefertigt werden soll:

Serienproduktion

Stückzahl pro Jahr

Lieferzeit*

Daten (ZIP)

Bei einer Leiterplattenbestückung benötigen wir von Ihnen: Leiterplattendaten (Gerber, Eagle, KiCAD), Pick-n-Place-File, BOM/Stückliste als Excel-Datei, Bestückungsplan als PDF-Datei. Die maximale Größe der Upload-Datei beträgt 10 MB.

Werden Bauteile von Ihnen bereitgestellt? Falls ja, welche?

Anmerkungen

Ich erkläre mich mit den Datenschutzbestimmungen dieser Website einverstanden

Diese Feld nicht ausfüllen!

Products

Are you looking for more than just an Pcb Factory? Maybe we can help you.

We have experience in development and project implementation in the area of hardware development at project level and are happy to help you wherever we can.

FAQ

Which designs can be equipped?

.SMD assembly up to package 01005 (three registration marks required per assembly side), BGA up to 0.6mm and fine pitch up to 0.4mm

.Any type of THT component

What delivery times are possible?

1 2-layer pcb------------quickest 12hours
2 4-layer pcb------------quickest 24hours
3 6-layer pcb------------quickest 48hours
4 8-layer pcb------------quickest 72hours

What need to be taken into account when providing Files?

Gerber file
PCB file
CAM file
ODB fIle
CAD fIle
Schematic drawing

What are the pcb capabilities of PRSGROUP?

Layers	1-36L
Board thickness	0.1-8.0mm
High Frequency	PTFE，Ceramic、Rogers
HDI	HDI
HDI Stage	1-5 Stage（≥6 Stage need to appraisal）
Min PCS size	pcs size 5*5mm（less than 3mm need to appraisal）
Max Panel size	21*33inch
Max Finish copper thickness	12OZ
Min Finish copper thickness	1/2oz
Layer to layer accuracy	≤3mil
Board thickness of Resin	0.2-6.0mm
Board thickness tolerance	Thickness≤1.0mm；±0.1mm Thickness＞1.0mm；±10%
Impedance tolerance	±5Ω（＜50Ω），±10%（≥50Ω）；Min±8%（≥50Ω）
Bow and twist	Normal:0.75%，Min:0.5% Max:2.0%
Lamination times	one core ≤5 times

What materials we can supply?

Item	Project name	Process capability
Material Type	Normal TG FR4	SY S1141、KB 6160A
	Middle TG FR4	SY S1150G、KB6165 F、KB6165G(HF)
	High TG FR4	SY S1000-2、SY S1165(HF)、KB 6167G(HF)、KB 6167F、TU-768、TU-872、VT-47；
	Aluminum	GL12、SPS-AL-01、CH-AL-LM3
	CTI 600	SY S1600
	High Frequency	Rogers4350、Rogers4003;Arlon 25FR、25N;
	PTFE	Rogers series、Taconic series、Arlon series、F4Bseries 、TP series
	Minture+FR4	Rogers、Taconic、Arlon、Nelco、F4B+FR-4

what are our quality controls?

We are constantly improving the quality of our products to meet the needs of our customers. Customer satisfaction and trust is our eternal work. Finally, through the efforts of all our staff, we obtained ISO9001:2008 certification and used world-class test instruments

what are our equipments?

PRODUCTION LINE

PRSGROUP has been a professional supplier of PCB fabrication, PCB assembly and components sourcing turnkey solutions since 2010. With a strong sales and technical support team, PRSGROUP is online 24 hours per day to meet customers' needs. Dedicated to improving prototypes for design engineers through the production process, from quotation to delivery, from PCB design and layout, PCB fabrication and turnkey PCB assembly, PRSGROUP offers unparalleled customer services.

Chengdu Cesgate Technology Co., Ltd factory production line 0

PRSGROUP have the ISO9001 & TS16949 certified. And 85% of our sales are oversea sales and export to Europe, United sates and Asian. Most of our boards are used for Aerospace, Military, Medical, Semiconductor, industrial, power, and other products. No matter what your company's main product is, PRSGROUP's production capacity and product coverage can always meet your needs.

Chengdu Cesgate Technology Co., Ltd factory production line 1

PRSGROUP enterprise management system adopts Jiulianhuan ERP. We advocate technological innovation, give full play to the leading role of new technology in enterprise operation, meet the various needs of customers as our responsibility, and provide customers with comprehensive technical support and services related to printed boards.

Chengdu Cesgate Technology Co., Ltd factory production line 2

Our products include: multilayer PCB, high frequency PCB, metal base (core) PCB, high Tg thick copper foil PCB, planar winding PCB, mixed dielectric PCB, HDI, rigid-flex PCB, special substrates and customized for various specific requirements printed circuit board. Our products are widely used in high-tech fields such as communication, power supply, computer network, digital products, industrial control, science and education, medical treatment, aerospace and national defense.

Chengdu Cesgate Technology Co., Ltd factory production line 3

PCB component sourcing is very critical and should be done through experienced suppliers, distributors, and manufacturers. We have worldwide networking and link to experts who can help you get the best in the market. As an experienced supplier, we can identify counterfeits and provide other services which are relevant during component sourcing like product testing. Therefore, PCB component sourcing should be treated with a lot of care because its success determines final product quality.

Chengdu Cesgate Technology Co., Ltd factory production line 4

Still having problems with PCB/SMT/components sourcing, talk to us today.

What are our advantages?

1 Better price than your any other supplies
2 Best price can ever get
3 Help you save more cost
4 Best price for mass production orders in China

Contact

Company: PRSGROUP COMPANY LIMITED

Web: www.prsgroup.cn/www.prs-group.cn

E mail: sales@prsgroup.cn

Tel: 0769-86011639

Fax: 0769-81328381
Skype: 22535deb2e3310ed

Address: Buling A No.2 4 street of Southwest Villiage,Shijie ,Dongguan Guangdong China

PCB FACTORY WITH THE BEST PRICES EVER
